圖解新款汽車傳感器結構、原理與檢修
定 價：88 元
- 作者：劉強
- 出版時間：2020/9/1
- ISBN：9787121383304
- 出 版 社：電子工業出版社
- 中圖法分類：U463.6
- 頁碼：344
- 紙張：
- 版次：01
- 開本：16開
本書在系統介紹傳感器結構與測量原理的基礎上，系統總結了汽車傳感器的結構類型、常見故障及影響、故障檢測方法，并給出了典型汽車傳感器檢測實例。本書還系統介紹了最新及常用汽車傳感器的安裝位置、結構原理、電路圖、動態檢測方法、靜態檢測方法及更換調整等內容。內容涉及：空氣流量傳感器，溫度傳感器，壓力傳感器，位置與角度傳感器，爆震與碰撞傳感器，氣體濃度傳感器，速度傳感器，其他執行器、傳感器。本書內容豐富，具有較強的實用性和可操作性，適合現代汽車維修人員及相關技術人員參考使用，也可作為大中專院校汽車專業的教材及汽車檢測相關專業學生的參考書。
劉強，畢業于吉林大學車輛工程系，碩士研究生學歷，從事電動車的研究和教學工作，在《汽車與維修》雜志多次發表署名文章，在電動車的檢修業界有一定的影響力。
第一章 空氣流量傳感器··················································································.1
第一節 熱線式空氣流量傳感器......................................................................................... 1
第二節 熱膜式空氣流量傳感器......................................................................................... 5
第二章 溫度傳感器························································································.17
第一節 概述.......................................................................................................................17
第二節 熱敏電阻式溫度傳感器.......................................................................................18
第三章 壓力傳感器·························································································.36
第一節 進氣壓力傳感器...................................................................................................36
第二節 其他壓力傳感器...................................................................................................46
第四章 位置與角度傳感器··············································································83
第一節 節氣門及加速踏板位置傳感器...........................................................................83
第二節 曲軸位置傳感器.................................................................................................105
第三節 凸輪軸位置傳感器............................................................................................. 118
第四節 其他位置傳感器.................................................................................................122
第五章 爆燃、碰撞傳感器················································································158
第一節 概述.....................................................................................................................158
第二節 爆燃傳感器.........................................................................................................159
第三節 碰撞傳感器.........................................................................................................168
第六章 氣體濃度傳感器·················································································.176
第一節 氧傳感器.............................................................................................................176
第二節 NOx傳感器.........................................................................................................188
第三節 煙塵濃度傳感器.................................................................................................191
第七章 速度傳感器························································································.194
第一節 輪速傳感器.........................................................................................................194
第二節 組合式加速度傳感器.........................................................................................204
第八章 其他執行器、傳感器···········································································.208
第一節 點火系統執行器.................................................................................................208
第二節 變速器多功能擋位開關......................................................................................212
第三節 雨量感應傳感器.................................................................................................213
第四節 本田扭矩傳感器.................................................................................................218
第五節 新款皇冠分相器轉矩傳感器.............................................................................221
第六節 大眾磁阻式扭矩傳感器.....................................................................................227
第七節 豐田卡羅拉巡航控制系統.................................................................................230
第八節 奧迪A4 轎車太陽能天窗..................................................................................236
第九節 制動器摩擦片磨損傳感器.................................................................................238
第十節 日照光電傳感器.................................................................................................240
第十一節 空氣濕度傳感器.............................................................................................242
第十二節 空氣質量傳感器.............................................................................................245
第十三節 制冷劑溫度傳感器.........................................................................................248
第十四節 散熱器識別傳感器.........................................................................................249
第十五節 擋位識別傳感器.............................................................................................251
第十六節 智能型蓄電池傳感器.....................................................................................253
第九章 傳感器的波形分析···············································································256
第一節 汽車電子信號.....................................................................................................256
第二節 傳感器的波形測試.............................................................................................260
第十章 傳感器故障案例·················································································.267
第十一章 新款捷達轎車電路圖·········································································317
